AUDAC COM104 audio amplifier Public Address (PA) system Black, White
Public Address Amplifier, 40W, 100/ 70 V / 4 Ω, RCA / 3.5 mm Jack
Description
The COM104 is a compact but versatile public address mixing amplifier which offers solutions for small to medium size audio systems in commercial installations. Typical applications are background music systems in retail stores, bars, restaurants and office buildings.
The compact and simple design allows installation in any location and operation through any possible user.
The amplifier is designed using Class-D amplifier technology and delivers an output power of 40 Watt to constant voltage (100V and 70V) or low impedance (4 Ohm) audio systems. A switch mode power supply allows compatibility with a wide variation of mains voltages for global compatibility.
A stereo line input allows connection for a wide variation of audio sources such as media players, radio tuners, internet audio players, … and many more. A balanced mic/line input allows connection for an announcement microphone with compatibility for condenser microphones using the integrated phantom power supply (15V). A priority switch overrides the background music when enabled, and compatibility with voice file players is guaranteed by the wide gain adjustment possibility (0 dB – +50 dB).
The COM104 is a table-top standing device, while rack mounting in 10.5″ or 19″ equipment racks is possible using an optionally available mounting set (MBS310).
Additional information
| Amplifier class | D |
|---|---|
| Total Harmonic Distortion (THD) | 0.5% |
| Signal-to-Noise Ratio (SNR) | 90 dB |
| Crosstalk (1kHz) | 70 dB |
| Output impedance | 4 Ω |
| Frequency range | 20 – 20000 Hz |
| Connectivity technology | Wired |
| Product colour | Black, White |
| AC input voltage | 100 – 240 V |
| AC input frequency | 50 – 60 Hz |
| Width | 217.5 mm |
| Depth | 300 mm |
| Height | 43.7 mm |
| Weight | 3 kg |
| Operating temperature (T-T) | 0 – 40 °C |
| Operating relative humidity (H-H) | 0 – 95% |
| RMS rated power | 40 W |
| AC (power) in | Yes |
| Line inputs (RCA) | 1 |
| Microphone in | Yes |
| Number of Euroblock input connectors | 1 |
| Number of Euroblock output connectors | 1 |
| Purpose | Public Address (PA) system |
| Gain adjustment | Rotary |
| On/off switch | Yes |
| Material | Steel |
| Rack capacity | 1U |
| Warranty period | 5 year(s) |
| Compliance certificates | CE |
| Power source type | AC |
| Power protection features | Overheating, Overload, Short circuit |
| LED indicators | Yes |
| Package weight | 4 kg |
| Speakers connectivity type | RCA/3.5mm/Euroblock |
| Impedance | 4 Ω |
| Bass adjustment | Yes |
| Treble adjustment | Yes |
